CAB202F Under Shelf Asymmetric Angled Slim Recessed Linear Light
CAB202F is designed to produce a uniformdistribution of diffused light in wooden platforms. CAB202F has anarrow base and is suitable for under cabinet, stair nosing andwall unit linear light designs. This channel comes in variablelengths up to 8 feet.
Characteristics
CAB202F is a recessed light made of extruded aluminumhousing, capped with a flexible flush frosted lens.
This linear LED luminaire is designed to produce a uniformdistribution of diffused light in wooden platforms. CAB202F has anarrow base and is suitable for under cabinet, stair nosing andwall unit linear light designs. This channel comes in variablelengths up to 8 feet.
*Cab series are complemented with dimmable, energy-efficient,dot-free LED, producing high color rendering index lighting. Thebright white LED light source with CCT options from 2200K to6000K provides the environment with desired lighting that fits thedesign concept.
The lighting system can be conveniently controlled with wallremote, hand remote, and smart app options. CAB202F is aperfect fit for use in residential and commercial to produceambient or decorative illumination.
EnoLight lighting solutions are designed and manufactured inCanada to the highest industry standards with 5 years warranty.
Electrical
Input
24 Volt DC
4 W/ft – 12 W/m
Power Supply
Class 2 Flicker-Free Dimming
Lutron Hi-lume Premier 0.1%
Lutron 3-wire 100%-1%
Protections: Short circuit, Over current, Over voltage
Operating Temp
-31°F to + 113°F
-35°C to + 45°C
Certification
U.S./Canada UL approved Type IC Recessed
Control
Options
Combination of remote and wireless wall dimmers
Smart light control mobile app
Multi-zone
Individual and zone options for color temperature and brightness control
Dimming
Brightness and cool to warm light mode with memory saving options
Physical
Dimension
WxH: 0.49 in x 0.41 in – 12mm x 10mm
Length: Up to 10 ft – 3 m
Weight: 0.08 lbs/ft – 0.12 kg/m
Finish
Mill, black, white, Silver anodized finish
Field
Damp and dry applications
Mounting
Recessed in drywall, wall and ceiling boards
Light
LED Type
Single white, tunable white, Circadian BIOS SkyBlue
CCT
3000K 3500K 4000K 4500K 5000K 5500K
CRI Varieties
97 full spectrum natural color with bright contrast
Brightness
200 Lm/ft – 700 Lm/m
Life time
50,000 hours
Warranty
5 years warranty
